2000VA Pure sine wave solar Inverter

1) Built-in high efficiency MPPT(Max Power Point Tracking) solar charger controller;

2) True C.R.G.O toroidal transformer, lower static loss, more energy saving;

3) Double CPU control, higher reliability;

4) PV priority mode or AC priority mode optional;

5) With AC charger function, charges your battery even without sunshine;

Categories: Hybrid Solar Inverter

WS-series(WSKE/WSKB/WSKC)Pure sine wave inverter
Model WSKB-500 WSKB-800 WSKB-1000 WSKB-1500
Rated Power 300W 500W 700W 1050W
Battery voltage 12Vdc 12Vdc 12Vdc 24Vdc
Working PV(photovoltaic priority) AC(AC priority)
PV Input voltage range 15Vdc-50Vdc 30V-50Vdc
Max. charge current  10A/20A/30A/40A optional
Max. conversion effciency 98%
Display Panel indicator light LED graphic screen+LED lights
Mains status
Optional
Input voltage range 140-275Vac
Input frequency range 45Hz-65Hz(auto transfer to inverter mode when over frequency)
Output voltage range 195-240Vac
Input PF.(AC/DC 98%
Efficiency Mains mode
Charge Current 10A
Mains overload warning until load decrease
Short circuit Yes
Inverter Output Inverter output voltage 220V+-3%
Output frequency 50Hz/60Hz+- 0.3Hz
Output power factor =0.8
Waveform distortion linear load<=3%
PV-AC transfer time 4ms typical value Max. 6ms
Efficiency inverter mode>=80%
Inverter overload 110-130% shutdown at 30s130-150% shutdown at 3s
Short circuit system automatically shut down
Alarm Mains abnormal 1time/1ssilence auto after 5s/ 5s
Low battery 1time/1s and flash battery last grid
Overload 1time/1s and display"overload" grid
Communication interface RS232
Others Output socket universal socket/customized
Surge protection optuional
Ambient temperature 0-40°
Ambient 10%-90%RHnon-condesing
Noise <=50db
Machine dimension (mm) 259x257x149 310x312x167
Qty/Ctn  2 2 1 1
Packing dimension 670x360x235 420x400x265
Packing weight 7.8 8.4 9.8 10.8
